Description
This is an RFID 13.56MHz NFC Smart Card used for Contactless transmission of data and supplies energy with no battery needed. Its Operating distance is Up to 1 Meter depending on antenna geometry. Operating frequency is 13.56MHz and Data transfer speed is 106 Kbit/s.
Our Observation and Recommendation:
The iPhone 13 Pro Max does not support this Card by default. We had to write the URL using a Samsung Galaxy device. After writing the URL to the card, it then worked on the iPhone 13 Pro Max. However, if we write anything other than a URL, such as text or a contact card, the iPhone doesn’t detect the tag. On our Samsung Galaxy device, it worked by default and we could write data onto it.
We cannot guarantee that it will work on every phone. Please keep this in mind before making a purchase.
Applications :
- Public transportation
- Access control
- Event Ticketing
- Gaming & identity
Features:
- Contactless transmission of data and supply energy (no battery needed)
- Anti-collision
- EEPROM
- 1Kbit, organized in 16 sectors, with each district with two passwords
- Data retention of 10 years.
- Security
- Individual key set per sector (per application) to support multi-application with key hierarchy
- A unique serial number for each device
- Transport key protects access to EEPROM on-chip delivery.
| General Specification | |
| Material | PVC |
| Operating Distance | Up to 100mm (depending on antenna geometry) |
| Operating Frequency | 13.56MHz |
| Data Transfer | 106 kbit/s |
| Data Integrity | 16 Bit |
| Typical Ticketing Transaction | <100 ms |
| Data Storage Time | minimum 10 years |
| Dimensions | 86 x 54mm |
| Thickness (mm) | 0.88 |
| Operating Temperature (°C) | -20 to 60 |
| Shipment Weight | 0.02 kg |
| Shipment Dimensions | 5 x 3 x 1 cm |
