Description
MN TLC plate coated with a soft layer of unmodified silica gel 60. Thickness of layer for analytical plates 0.25 mm. For preparative purposes (PLC) different layer thickness are available (0.5 mm, 1 mm and 2 mm). For 2 mm preparative layers a slightly coarser material is used. Available with different UV indicators – manganese activated zinc silicate with green fluorescence for short-wave UV (254 nm); special inorganic fluorescent pigment with blue fluorescence for long-wave UV (366 nm). SIL G is available on glass plates, aluminum sheets and polyester sheets in different sizes.
- TLC aluminum sheets, silica gel layer, ALUGRAM Xtra SIL G UV254, 20×20 cm
- TLC aluminum sheets with optimized cuttability and wettability. Layer – unmodified silica gel (SiOH).
- Hazardous material: No
- Method Thin layer chromatography (TLC)
- Brand ALUGRAM Xtra
- Phase Xtra SIL G UV254
- Base material Aluminum sheets coated with silica gel
- Surface chemistry Unmodified silica gel (SiOH)
- Mode Normal phase (NP)
- Plate size 20×20 cm
- Layer thickness 0.20 mm
- Layer hardness Standard, soft
- UV indicator Yes
- Support material/backing Aluminum
- Particle size: 5-17µm
- Particle type Fully porous particles (FPP)
- Particle shape Irregular
- Pore size: 60Å
- Pore volume 0.75 mL/g
- Binder: Yes
- pH stability 2.0-8.0
- Recommended applications of the MN TLC Plate is Aflatoxins, Alkaloids, Amines, Amino acids, Analgetics, Antibiotics, Hormones, Marihuana compounds, Normal phase (NP), Patulin, Steroids, Sweeteners, Vitamins
- Temperature stability High
- Storage temperature RT
- Scope of delivery 25x TLC aluminum sheets/foils (20×20 cm)
- Made IN Germany
- Click for More Information
